Shared state to support multi screen inspection by CoderDake · Pull Request #129452 · flutter/flutter

CoderDake · 2023-06-23T21:52:02Z

With Multi View applications on the way, we need to be able to manage the state of multiple Inspector widgets in a consistent way.

Previously each Widget inspector would manage the state of it's own inspection. This made for a confusing and inconsistent experience when clicking on the widget inspector of different views.

This PR changes the state management to the WidgetInspectorService static instance so that all widget inspectors can share that state.

Demo

Screen.Recording.2023-07-10.at.4.26.37.PM2.mov

jacob314

Overall looks like it is on the right track.

wanjm · 2023-07-15T06:16:58Z

where can i get the multi window example in the above video;

CoderDake · 2023-07-17T17:10:25Z

@wanjm It can be found here:
https://github.com/goderbauer/mvp

CoderDake · 2023-07-21T20:34:07Z

Fixes flutter/devtools#5935

CoderDake · 2023-07-21T20:41:55Z

Fixes flutter/devtools#5931

jacob314 · 2023-07-27T21:16:49Z

-    final double maxWidth = size.width - 2 * (_kScreenEdgeMargin + _kTooltipPadding);
+    final double maxWidth = math.max(
+      size.width - 2 * (_kScreenEdgeMargin + _kTooltipPadding),
+      0,


good catch! should we just short circuit and not try to draw anything is maxWidth <= 0?

Perhaps we could but I don't know enough about these cases to know if we always want to.

jacob314

LGTM once these small nits are resolved.

…o multi-screen-inspection-state

goderbauer

LGTM

jacob314
